Rectangular Hollow Section

UK Sizes & Dimensions

Material to:

EN 10025-2:2004

Dimensions and properties to:

BS4-1:2005

Cut to Length

Custom lengths available

Fast Delivery

Quick turn-arround to site

UK Size Chart

Full UB dimensions table

Universal Beams

Universal Columns

Parallel Flange Channel

Equal Angle Iron

Uneaqual angle

Flat Bar

Square Hollow Section

Rectangular Hollow Section

Reinforcing Bar

Circular Hollow Section

Steel Sheet

size info (MM)

Size Kg Height Width Web Thk Flange Thk Diameter Action
80 X 40 X 3 5.3 80 40 3 - Request Quote
80 X 40 X 3.2 5.6 80 40 3.2 - Request Quote
80 X 40 X 3.6 6.3 80 40 3.6 - Request Quote
80 X 40 X 4 6.9 80 40 4 - Request Quote
80 X 40 X 5 8.4 80 40 5 - Request Quote
80 X 40 X 6 9.9 80 40 6 - Request Quote
80 X 40 X 6.3 10.3 80 40 6.3 - Request Quote
80 X 40 X 8 12.5 80 40 8 - Request Quote
90 X 50 X 3 6.2 90 50 3 - Request Quote
90 X 50 X 3.2 6.6 90 50 3.2 - Request Quote
90 X 50 X 3.6 7.4 90 50 3.6 - Request Quote
90 X 50 X 4 8.2 90 50 4 - Request Quote
90 X 50 X 5 10 90 50 5 - Request Quote
90 X 50 X 6 11.8 90 50 6 - Request Quote
90 X 50 X 6.3 12.3 90 50 6.3 - Request Quote
90 X 50 X 8 15 90 50 8 - Request Quote
100 X 50 X 3 6.7 100 50 3 - Request Quote
100 X 50 X 3.2 7.1 100 50 3.2 - Request Quote
100 X 50 X 3.6 8 100 50 3.6 - Request Quote
100 X 50 X 4 8.8 100 50 4 - Request Quote
100 X 50 X 5 10.8 100 50 5 - Request Quote
100 X 50 X 6 12.7 100 50 6 - Request Quote
100 X 50 X 6.3 13.3 100 50 6.3 - Request Quote
100 X 50 X 8 16.3 100 50 8 - Request Quote
100 X 60 X 3 7.2 100 60 3 - Request Quote
100 X 60 X 3.2 7.6 100 60 3.2 - Request Quote
100 X 60 X 3.6 8.5 100 60 3.6 - Request Quote
100 X 60 X 4 9.4 100 60 4 - Request Quote
100 X 60 X 5 11.6 100 60 5 - Request Quote
100 X 60 X 6 13.6 100 60 6 - Request Quote
100 X 60 X 6.3 14.2 100 60 6.3 - Request Quote
100 X 60 X 8 17.5 100 60 8 - Request Quote
120 X 60 X 3.6 9.7 120 60 3.6 - Request Quote
120 X 60 X 4 10.7 120 60 4 - Request Quote
120 X 60 X 5 13.1 120 60 5 - Request Quote
120 X 60 X 6 15.5 120 60 6 - Request Quote
120 X 60 X 6.3 16.2 120 60 6.3 - Request Quote
120 X 60 X 8 20.1 120 60 8 - Request Quote
120 X 60 X 10 24.6 120 60 10 - Request Quote
120 X 80 X 3.6 10.8 120 80 3.6 - Request Quote
120 X 80 X 4 11.9 120 80 4 - Request Quote
120 X 80 X 5 14.7 120 80 5 - Request Quote
120 X 80 X 6 17.4 120 80 6 - Request Quote
120 X 80 X 6.3 18.2 120 80 6.3 - Request Quote
120 X 80 X 8 22.6 120 80 8 - Request Quote
120 X 80 X 10 27.4 120 80 10 - Request Quote
140 X 80 X 4 13.2 140 80 4 - Request Quote
140 X 80 X 5 16.3 140 80 5 - Request Quote
140 X 80 X 6 19.3 140 80 6 - Request Quote
140 X 80 X 6.3 20.2 140 80 6.3 - Request Quote
140 X 80 X 8 25.1 140 80 8 - Request Quote
140 X 80 X 10 30.6 140 80 10 - Request Quote
150 X 100 X 4 15.1 150 100 4 - Request Quote
150 X 100 X 5 18.6 150 100 5 - Request Quote
150 X 100 X 6 22.1 150 100 6 - Request Quote
150 X 100 X 6.3 23.1 150 100 6.3 - Request Quote
150 X 100 X 8 28.9 150 100 8 - Request Quote
150 X 100 X 10 35.3 150 100 10 - Request Quote
150 X 100 X 12 41.4 150 100 12 - Request Quote
150 X 100 X 12.5 42.8 150 100 12.5 - Request Quote
160 X 80 X 4 14.4 160 80 4 - Request Quote
160 X 80 X 5 17.8 160 80 5 - Request Quote
160 X 80 X 6 21.2 160 80 6 - Request Quote
160 X 80 X 6.3 22.2 160 80 6.3 - Request Quote
160 X 80 X 8 27.6 160 80 8 - Request Quote
160 X 80 X 10 33.7 160 80 10 - Request Quote
160 X 80 X 12 39.5 160 80 12 - Request Quote
160 X 80 X 12.5 40.9 160 80 12.5 - Request Quote
180 X 100 X 4 16.9 180 100 4 - Request Quote
180 X 100 X 5 21 180 100 5 - Request Quote
180 X 100 X 6 24.9 180 100 6 - Request Quote
180 X 100 X 6.3 26.1 180 100 6.3 - Request Quote
180 X 100 X 8 32.6 180 100 8 - Request Quote
180 X 100 X 10 40 180 100 10 - Request Quote
180 X 100 X 12 47 180 100 12 - Request Quote
180 X 100 X 12.5 48.7 180 100 12.5 - Request Quote
200 X 100 X 4 18.1 200 100 4 - Request Quote
200 X 100 X 5 22.6 200 100 5 - Request Quote
200 X 100 X 6 26.8 200 100 6 - Request Quote
200 X 100 X 6.3 28.1 200 100 6.3 - Request Quote
200 X 100 X 8 35.1 200 100 8 - Request Quote
200 X 100 X 10 43.1 200 100 10 - Request Quote
200 X 100 X 12 50.8 200 100 12 - Request Quote
200 X 100 X 12.5 52.7 200 100 12.5 - Request Quote
200 X 100 X 16 65.2 200 100 16 - Request Quote
200 X 120 X 6 28.7 200 120 6 - Request Quote
200 X 120 X 6.3 29.9 200 120 6.3 - Request Quote
200 X 120 X 8 37.3 200 120 8 - Request Quote
200 X 120 X 10 45.9 200 120 10 - Request Quote
200 X 120 X 12 54.5 200 120 12 - Request Quote
200 X 120 X 12.5 55.7 200 120 12.5 - Request Quote
250 X 150 X 5 30.4 250 150 5 - Request Quote
250 X 150 X 6 36.2 250 150 6 - Request Quote
250 X 150 X 6.3 38 250 150 6.3 - Request Quote
250 X 150 X 8 47.7 250 150 8 - Request Quote
250 X 150 X 10 58.8 250 150 10 - Request Quote
250 X 150 X 12 69.6 250 150 12 - Request Quote
250 X 150 X 12.5 72.3 250 150 12.5 - Request Quote
250 X 150 X 16 90.3 250 150 16 - Request Quote
260 X 180 X 6 40 260 180 6 - Request Quote
260 X 180 X 6.3 41.9 260 180 6.3 - Request Quote
260 X 180 X 8 52.7 260 180 8 - Request Quote
260 X 180 X 10 65.1 260 180 10 - Request Quote
260 X 180 X 12 77.2 260 180 12 - Request Quote
260 X 180 X 12.5 80.1 260 180 12.5 - Request Quote
260 X 180 X 16 100 260 180 16 - Request Quote
300 X 200 X 5 38.3 300 200 5 - Request Quote
300 X 200 X 6 45.7 300 200 6 - Request Quote
300 X 200 X 6.3 47.9 300 200 6.3 - Request Quote
300 X 200 X 8 60.3 300 200 8 - Request Quote
300 X 200 X 10 74.5 300 200 10 - Request Quote
300 X 200 X 12 88.5 300 200 12 - Request Quote
300 X 200 X 12.5 91.6 300 200 12.5 - Request Quote
300 X 200 X 16 115 300 200 16 - Request Quote
350 X 250 X 6 55.1 350 250 6 - Request Quote
350 X 250 X 6.3 57.8 350 250 6.3 - Request Quote
350 X 250 X 8 72.8 350 250 8 - Request Quote
350 X 250 X 10 90.2 350 250 10 - Request Quote
350 X 250 X 12 107.0 350 250 12 - Request Quote
350 X 250 X 12.5 112.0 350 250 12.5 - Request Quote
350 X 250 X 16 141 350 250 16 - Request Quote
400 X 200 X 6 55.1 400 200 6 - Request Quote
400 X 200 X 6.3 57.8 400 200 6.3 - Request Quote
400 X 200 X 8 72.8 400 200 8 - Request Quote
400 X 200 X 10 90.2 400 200 10 - Request Quote
400 X 200 X 12 107.0 400 200 12 - Request Quote
400 X 200 X 12.5 112.0 400 200 12.5 - Request Quote
400 X 200 X 16 141.0 400 200 16 - Request Quote
450 X 250 X 8 85.4 450 250 8 - Request Quote
450 X 250 X 10 106.0 450 250 10 - Request Quote
450 X 250 X 12 126.0 450 250 12 - Request Quote
450 X 250 X 12.5 131.0 450 250 12.5 - Request Quote
450 X 250 X 16 166.0 450 250 16 - Request Quote
500 X 300 X 8 97.9 500 300 8 - Request Quote
500 X 300 X 10 122.0 500 300 10 - Request Quote
500 X 300 X 12 145.0 500 300 12 - Request Quote
500 X 300 X 12.5 151.0 500 300 12.5 - Request Quote
500 X 300 X 16 191.0 500 300 16 - Request Quote
500 X 300 X 20 235 500 300 20 - Request Quote
